Extremely safe and stable chemistry: PCB and/or BMS built inside to protect the battery.
Long life-cycle: Best can up to 2000 times recycles, 8 times of Lead acid battery.
Lighter weight, with the best power-to-weight ratio: 1/3 of Lead acid battery weight.
Good performance at high temperature.
Low self-discharge rate, less than 3% monthly.
Environment friendly: Non-toxic, non-contaminating and no rare metal. Passed Reach
|
No.
|
Item
|
General Parameter
|
Remark
|
| 1 |
Rated Capacity |
23.0Ah |
Standard discharge(0.2 C5)after standard charge(0.2 C5)
|
| 2 |
Minimal Rated |
21.85Ah | |
| 3 |
Nominal Voltage |
12.8V | |
| 4 |
Cycle Life |
Higher than 60% of the Initial Capacity of the Cells |
Charge: CC@0.2C to 14.6V, then CV till current to 0.05C |
| 5 | Discharge cut-off voltage | 8.0V | |
| 6 | Charging cut-off voltage | 14.6V | |
| 7 | Cell and assembly method | IFR26650-3.3AH | 4S7P |
| 8 | Housing material | Flame retardent plastic |
Large-scale electric vehicles: electric bus, electric car, E-Tour Car
Light electric car: e-bike, e-scooter,e-motorcycle, electric golf cart, e-wheelchair
tool: electric drill, electric saw, lawn mower and so on
Remote control cars, boat, aircraft, toys
Solar and wind power generation energy storage devices, Small medical equipment and portable equipment.
The battery pack was putted into transpare bag, 1 set for one box , 2 box for one carton
Maybe you are interested in more model as below
| Model Name | Battery Chemical | Nominal Voltage | Out put Voltage | Max Discharge Current | G.W. | Cell Inside | Assembling | |
| Max | Min | |||||||
| INM24V8.8Ah | Li(MnNiCo)O2 | 25.9V | 29.4V | 21V | 15A | 2.8KG | INR18650 2200mAh | 7S4P |
| INM24V10.4Ah | Li(MnNiCo)O2 | 25.9V | 29.4V | 21V | 15A | 3.0KG | INR18650 2600mAh | 7S4P |
| INM36V8.8Ah | Li(MnNiCo)O2 | 37V | 42V | 30V | 15A | 3.4KG | INR18650 2200mAh | 10S4P |
| INM36V10.4Ah | Li(MnNiCo)O2 | 37V | 42V | 30V | 15A | 3.5KG | INR18650 2600mAh | 10S4P |
| IMM24V10Ah | LiMnO4 | 25.9V | 29.4V | 21V | 15A | 2.99KG | Enax Lithium Polymer | 7S1P |
| IMM36V10Ah | LiMnO4 | 37V | 42V | 30V | 15A | 3.7KG | Enax Lithium Polymer |
7S1P
|
|
IFM24V9.9Ah
|
LiFePO4
|
25.6V
|
29.2V
|
16V
|
15A
|
3.5KG
|
IFR26650 3300mAh
|
8S3P
|
